Coam and Cam are the modified static and dynamic load capacities,calculated according to ISO-3408-5

Model No. Screw Dia. Lead Modified Load Capacity(kgf) Screw Shaft Length Accuracy
Grade		 Axial Play Lead Accuracy Tolerances Fixed End–bearing(kgf) Supported End–bearing(kgf) 2D-CAD
(DWG)
d I

Dynamic Cam

 Static Coam L1 L2 L3 Specified
Travel (T)		 Travel (T)
Accumulated
reference lead
deviation (E)		 Lead Deriation in
random 300mm
(e300)		 Overall
Radial
Runout

Dynamic
Ca

 Static
Co

Dynamic
Ca

 Static
Co
BL025050600+A000 25 05 1440 3840 493 520 600 C5 < 0.005 0 0.027 0.018 0.050 1480 847 1030 597 cad button
BL025051000+A000 25 05 1440 3840 893 920 1000 C5 < 0.005 0 0.040 0.018 0.085 1480 847 1030 597 cad button
BL025051450+A000 25 05 1440 3840 1343 1370 1450 C5 < 0.005 0 0.054 0.018 0.130 1480 847 1030 597 cad button
