Coam and Cam are the modified static and dynamic load capacities,calculated according to ISO-3408-5

Model No. Screw Dia. Lead Modified Load Capacity(kgf) Screw Shaft Length Accuracy
Grade		 Axial Play Lead Accuracy Tolerances Fixed End–bearing(kgf) Supported End–bearing(kgf) 2D-CAD
(DWG)
d I

Dynamic Cam

 Static Coam L1 L2 L3 Specifi ed
Travel (T)		 Travel (T)
Accumulated
reference lead
deviation (E)		 Lead Deriation in
random 300mm
(e300)		 Overall
Radial
Runout

Dynamic
Ca

 Static
Co

Dynamic
Ca

 Static
Co
BL020100600+A000 20 10 990 2220 518 540 600 C5 < 0.005 0 0.030 0.018 0.075 622 352 408 252 cad button
BL020101000+A000 20 10 990 2220 918 940 1000 C5 < 0.005 0 0.040 0.018 0.120 622 352 408 252 cad button
BL020101450+A000 20 10 990 2220 1368 1390 1450 C5 < 0.005 0 0.054 0.018 0.190 622 352 408 252 cad button
