Note: Coam and Cam are the modified static and dynamic load capacities,calculated according to ISO-3408-5

Model No. Screw Dia. Lead Modified Load Capacity(kgf) Screw Shaft Length Accuracy
Grade		 Axial Play Lead Accuracy Tolerances Fixed End–bearing(kgf) Supported End–bearing(kgf) 2D-CAD
(DWG)
d I

Dynamic Cam

 Static Coam L1 L2 L3 Specified
Travel (T)		 Travel (T)
Accumulated
reference lead
deviation (E)		 Lead Deriation in
random 300mm
(e300)		 Overall
Radial
Runout

Dynamic
Ca

 Static
Co

Dynamic
Ca

 Static
Co
BL015100500+A000 15 10 840 1610 440 455 500 C5 < 0.005 0 0.025 0.018 0.060 592 304 372 204 cad button
BL015101000+A000 15 10 840 1610 940 955 1000 C5 < 0.005 0 0.040 0.018 0.120 592 304 372 204 cad button
BL015101450+A000 15 10 840 1610 1390 1405 1450 C5 < 0.005 0 0.054 0.018 0.190 592 304 372 204 cad button
