Note: Coam and Cam are the modified static and dynamic load capacities,calculated according to ISO-3408-5

Model No. Screw Dia. Lead Modified Load Capacity(kgf) Screw Shaft Length Accuracy
Grade		 Axial Play Lead Accuracy Tolerances Fixed End–bearing(kgf) Supported End–bearing(kgf) 2D-CAD
(DWG)
d I

Dynamic Cam

 Static Coam L1 L2 L3 Specified
Travel (T)		 Travel (T)
Accumulated
reference lead
deviation (E)		 Lead Deriation in
random 300mm
(e300)		 Overall
Radial
Runout

Dynamic
Ca

 Static
Co

Dynamic
Ca

 Static
Co
BL012100400+A000 12 10 590 1160 347 362 400 C5 < 0.005 0 0.023 0.018 0.065 546 265 196 106 cad button
BL012100600+A000 12 10 590 1160 547 562 600 C5 < 0.005 0 0.027 0.018 0.090 546 265 196 106 cad button
BL012100900+A000 12 10 590 1160 847 862 900 C5 < 0.005 0 0.035 0.018 0.150 546 265 196 106 cad button
