Description

All dimensions are same as SMR-E except the length is longer, which makes it more rigid.

Note*: Single: Single carriage/ Double: Double carriages closely contacting with each other.

Model No. External dimension Carriage dimension
Height
H		 Width
W		 Length
L		 W2

H2

 B

C

 S l L1 T N G K e1 G1 Grease Nipple
SMR 25S
SMR 25LS		 40 48 97.5
115.5		 12.5 4.8 35 35
50		 M6 10.5 65.5
83.5		 9.5 10 12 6.6 6.5 M6 G-M6
SMR 30S
SMR 30LS		 45 60 112.4
135.2		 16 6 40 40
60		 M8 12 75.9
98.7		 10 10 12 8 7 M6 G-M6
SMR 35S
SMR 35LS		 55 70 125.3
153.5		 18 6.5 50 50
72		 M8 14 82.3
110.5		 12 15 12 8 7 M6 G-M6
SMR 45S
SMR 45LS		 70 86 154.2
189.4		 20.5 8 60 60
80		 M10 19 106.5
141.7		 17 20 13.5 10 8 M6 G-PT 1/8
SMR 55S
SMR 55LS		 80 100 185.4
235.4		 23.5 10 75 75
95		 M12 19 129.5
179.5		 18 21 13.5 12 7.95 M6 G-PT 1/8
SMR 65LS 90 126 300.4 31.5 12 76 120 M16 20 230 19.5 16.5 13.5 12 8 M6 G-PT 1/8



Model No. Rail dimension Basic load rating Static moment rating Weight
Width
W1		 Height
H1		 Pitch
P		 E
std.

D × h × d

 Dynamic C
kN		 StaticCo
kN		 Mp
kN-m		 MY
kN-m		 MR
kN-m		 Carriage
kg		 Rail
kg/m
Single* Double* Single* Double*
SMR 25S
SMR 25LS		 23 23.5 30 20 11 × 9 × 7 27.4
33.1		 57.4
73.3		 0.63
1.01		 3.63
5.49		 0.63
1.01		 3.63
5.49		 0.66
0.84		 0.65
0.85		 3.5
SMR 30S
SMR 30LS		 28 27.5 40 20 14 × 12 × 9 39.5
49.4		 82.7
110.3		 1.01
1.78		 5.90
9.60		 1.01
1.78		 5.90
9.60		 1.15
1.53		 1
1.22		 5
SMR 35S
SMR 35LS		 34 30.5 40 20 14 × 15 × 9 55.6
69.6		 117.0
156.0		 1.63
2.86		 9.59
15.57		 1.63
2.86		 9.59
15.57		 1.98
2.63		 1.65
2.15		 7
SMR 45S
SMR 45LS		 45 37 52.5 22.5 20 × 17 × 14 89.3
110.6		 184.1
242.2		 3.27
5.6		 18.48
29.56		 3.27
5.6		 18.48
29.56		 4.18
5.5		 3.2
4.1		 11.2
SMR 55S
SMR 55LS		 53 43 60 30 23 × 20 × 16 127.8
163.2		 256.5
351.0		 5.51
10.16		 30.89
53.02		 5.51
10.16		 30.89
53.02		 6.96
9.52		 5.1
7		 15.6
SMR 65LS 63 52 75 35 26 × 22 × 18 263.5 583.7 21.43 111.99 21.43 111.99 18.73 13.3 22.4
